Understanding and Preventing Cracks in Molded Parts

Cracks in molded parts are one of the most common and concerning defects that can compromise part integrity. They can lead to failures in critical applications, resulting in costly recalls, repairs, and potential safety hazards. Understanding the types, causes, detection methods, and prevention strategies for cracks is crucial for anyone involved in the injection molding process. This post will delve into these aspects, providing insights and practical advice to help you minimize the occurrence of cracks in your molded parts.

What are Cracks in Molded Parts?

Cracking refers to the formation of fractures or breaks in the molded part, ranging from tiny hairline cracks to complete part failure. These cracks can occur during the molding process, immediately after molding, or develop over time. Cracks in injection molded parts are physical fractures or breaks that occur in the plastic material. They can significantly impact the quality, functionality, and aesthetics of the molded product.

Common Causes of Cracking Defects

Common Causes of Cracking in injection molded parts can be attributed to various factors. Understanding these causes is crucial for preventing and addressing cracking issues.

1. Molecular orientation issues:

Molecular orientation issues occur when polymer molecules align in a particular direction during the molding process. This alignment can lead to anisotropic shrinkage and warpage, causing stress and potential cracking. Those issues are often result from high injection speeds or inadequate packing pressure.

2. Residual stress:

Internal stresses that remain in the part after molding and cooling. The residual stress can be caused by uneven cooling rates, excessive packing pressure, or improper gate location. That may lead to stress cracking, especially when exposed to certain chemicals or environmental factors.

3. Design flaws:

a) Sharp corners: Sharp corners act as stress concentrators, increasing the likelihood of crack initiation. That can be mitigated by incorporating proper radii or fillets.

b) Insufficient draft angles: Improper draft angles make part ejection difficult and potentially cause stress and cracking. Recommended draft angles typically range from 0.5° to 3°, depending on the material and part geometry.

c) Improper mold design: Poor gate location, inadequate venting, or improper runner system design can contribute to cracking problems.

4. Processing problems:

a) Injection pressure: Too high injection pressure can cause excessive residual stress. Too low injection pressure may result in incomplete filling and weak weld lines.

b) Cooling rate: Uneven or rapid cooling can lead to internal stresses and warpage. Slow cooling may increase cycle time but can reduce residual stress.

c) Ejection issues: Premature or forceful ejection can cause stress and cracking, especially if the part is still too hot.

5. Material-related factors:

a) Moisture content: Excess moisture in hygroscopic materials can lead to hydrolysis during processing. They can cause degradation of material properties and increase the likelihood of cracking.

b) Contamination: Foreign particles or incompatible materials can create weak points in the molded part. That may lead to stress concentration and crack initiation.

6. Environmental factors:

Exposure to UV radiation, chemicals, or extreme temperatures can cause stress cracking in susceptible materials.

Crack Types and Causes

Based on the search results, here’s an overview of different crack types in injection molded parts and their causes:

1 Cracks in the direction of flow:

These cracks develop along the direction of plastic flow into the mold cavity. They are primarily caused by excessive molecular orientation, where the long-chain polymer molecules become too aligned in the flow direction. This can result from improper fill rates or cooling conditions.

2 Internal cracks:

These occur within rigid plastic parts and may not be immediately visible on the surface. They are caused by high internal stresses resulting from improper cavity pressure during molding. Internal cracks can often be seen in transparent parts before failure.

3 Corner cracks:

Cracks appearing in the corners of plastic parts are typically caused by excessive plastic shrinkage onto the mold core in that area. This issue is often accompanied by the part hanging up on the core during ejection.

4 Surface cracks:

These are tiny hairline cracks on the part’s surface that may develop days, months, or even years after molding. They are caused by molecular orientation at the surface combined with gradual weakening from chemical attack or sunlight exposure. Internal stress in the part eventually leads to these cracks appearing.

5 Gate area cracks:

Cracks that form near or at the gate location of a molded part are usually caused by high molecular orientation or excessive plastic pressure in the gate region. The gate area experiences the highest fill rates, leading to more molecular orientation.

Prevention Strategies for Cracks in Molded Parts

Troubleshooting and Prevention Strategies for cracks in injection molded parts involve a multi-faceted approach.

Adjusting molding parameters:

  • Injection speed: Reduce speed to decrease molecular orientation and internal stress. Optimize speed to ensure proper filling without excessive shear.
  • Pressure: Adjust injection pressure to ensure proper filling without over-packing. Fine-tune holding pressure to compensate for shrinkage without creating residual stress.
  • Temperature: Optimize melt temperature to ensure proper flow and reduce internal stress. Adjust mold temperature to control cooling rate and minimize warpage.

Optimizing part and mold design:

  • Part design: Incorporate proper radii on corners and edges to reduce stress concentration. Ensure uniform wall thickness to promote even cooling and reduce warpage. Add ribs or gussets to increase part strength without excessive thickness.
  • Mold design: Implement proper gate location and size to optimize flow and reduce stress. Ensure adequate venting to prevent air traps and incomplete filling. Design appropriate cooling channels for uniform heat extraction.

Material selection and handling:

  • Selection: Choose materials with appropriate mechanical properties for the application. Consider environmental factors (e.g., UV exposure, chemical resistance) in material selection.
  • Handling: Properly dry hygroscopic materials to prevent moisture-related issues. Avoid contamination during material handling and storage. Use appropriate additives or reinforcements to enhance material properties.

Post-molding considerations:

  • Cooling: Allow sufficient cooling time in the mold to reduce internal stress. Implement controlled cooling strategies for large or complex parts.
  • Handling: Develop proper procedures for part removal to prevent stress or damage. Use appropriate packaging to protect parts during storage and transportation.
  • Environment: Consider the end-use environment in part design and material selection. Implement stress-relieving techniques if necessary (e.g., annealing).

Conclusion

Cracks in molded parts are a common but preventable defect. That can impact product quality, functionality, and aesthetics. They are caused by different reasons. Effective prevention strategies will reduce the occurrence of cracks, improve product quality, and enhance overall efficiency in the injection molding process. Remember that preventing cracks often requires a balance between various factors, and finding the optimal solution may involve iterative improvements in the production process.
